Multi Channel 3g Gsm Sms Gprs Wifi Ethernet Temperature Humidity Alarm Data Logger Monitor System

T&H Feature

T&H wireless

logger on Cloud

• Logger mode: GPRS and Ethernet, option: Wi-Fi

• Customized logger interval

• History record query and export

• Support connect Max 4 cloud or local servers

T&H Real-Time

monitor on Cloud

• Real-time T&H on web with multi display modes

• Support T&H graph, list

• Multi-point monitoring

• Device status real-time display, online, offline, alarm

• Google map track device position

T&H alarm

• Customized low and high level for alarm

• T&H alarm on web with notice, icon and sound alert

• Sms alarm

• Cloud email alarm

• Device local sound and light alarm (if connect an alarm)

T&H Control

• Programmable local output control

• Sms remote control

• Control on web


CWT5018 Feature

Interface

• 32 channels for temperature humidity by RS485

• 2 outputs, can linkage with temperature alarm (e.g. siren, relay, switch)

• 4 digital inputs to receive alarm signal

• 8 analog inputs, read sensors (e.g. voltage, current, level )

• 1 RS232 for configuration

Data logger

• Cloud Data logger

• Customized logger interval

• Support connect Max 4 cloud or local servers

Wireless Network

• Either GPRS(option: 3G/4G, need Simcard) or Wi-Fi(Not need simcard

• To communicate with server with CWT_IO or Modbus TCP protocol

Ethernet

• Support ARP, DHCP, TCP, UDP protocol

• To communicate with server with CWT_IO or Modbus TCP protocol

SMS

(available for gsm/3g version)

• SMS alarm when high and low

• Editable SMS alarm texts

• Query current value via SMS command

• SMS report on schedule

• Power failure SMS alarm (need add inside battery)

• Can preset 10 cell phone numbers

• Can query SIM card balance, SMS forward

• Remote config via SMS

Technical Feature

• Network-reconnect and retransmission to ensure sms and data accurately transmit

• Inside watch dag to assures 7*24 hours working

• Optional inside 1000mA battery, life 8-20 hours

• With immediacy and reliability of the system

• GPS module optional

• Free configure software

CWT5018 SPECIFICATIONS

MCU

Cortex M3 32-bit ARM

Power supply

9-28V DC (Standard adapter: DC 12V/1.5A)

Consumption

12V input Max. 150mA/Average 50mA

Wireless Network

Either GPRS(option: 3G/4G, need simcard) or Wi-Fi(Not need simcard)

GSM/GPRS (4 band 850/900/1800/1900Mhz)

Option: WCDMA (3G), FDD LTE(4G) module

Wi-Fi, 802.11 b/g security WEP/WPA/WPA2

Ethernet

Communication rate:10/100M

GPS module

Optional

SIM/UIM

Standard user card interface

Terminals

2×14pin 3.81mm spacing, pluggable

Working temperature

-30℃～+70℃

Battery

lithium-polymer, 500mAh/3.7V，life:8-20 hours

Dimension

130×80×25mm

Housing

providing IP30 protection

Antenna

Standard SMA female interface (50Ω)

Working humidity

Relative humidity 95%

Weight

390g
